Kelier - co2 laser printer automatic date code printing machine 30 20 watt fiber laser marking machine CO2 laser marking machine
Utilizing technology makes the manufacturing process go smoothly and efficiently.With regard to the product advantages, the product can be widely found in the field(s) of co2 laser printer automatic date code printing machine 30 20 watt fiber laser marking machine. co2 laser printer automatic date code printing machine 30 20 watt fiber laser marking machine has made great technological breakthroughs because technicians often hold training and technical exchanges to improve professional skills. co2 laser printer automatic date code printing machine 30 20 watt fiber laser marking machine,as one of our best and latest products, deserved to be noticed widely and displayed to customers around the world.
| Application: | Laser Marking | Working Accuracy: | 0.001mm |
| Graphic Format Supported: | AI, DXF, PLT, BMP, Dst, Dwg, LAS, DXP, JPG | Laser Type: | Fiber Laser |
| Condition: | New | CNC or Not: | Yes |
| Cooling Mode: | Air Cooling | Control Software: | EZCAD borad |
| Place of Origin: | Sichuan, China | Brand Name: | Kelier |
| Laser Source Brand: | DAVI/CRD | Control System Brand: | EZCAD/NOAH |
| Marking Head Brand: | SINO GALVO | Weight (KG): | 15 KG |
| Key Selling Points: | High Safety Level | Warranty: | 3 years, 3 Years /laser Metal Printer |
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, co2 laser printer | Marking Area: | 175mm*175mm |
| Machinery Test Report: | Provided | Video outgoing-inspection: | Provided |
| Warranty of core components: | 1 Year | Core Components: | PLC |
| Marking Speed: | 0-9000mm/s | Marking Depth: | 0.01-1mm |
| Standard marking area: | 50mm*50mm--- 300mm*300mm | Laser generator Life: | 100,000hours |
| Frequency of pluse: | 20KHZ~80KHZ | Repeated accuracy: | 0.001mm |
| Laser source: | DAVI/CRD | Power supply: | AC220V/50Hz;110V/60Hz |
| Laser wavelength: | 1060nm | Certification: | ce |
| After-sales Service Provided: | Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support | After Warranty Service: | Video technical support, Spare parts |
| Local Service Location: | Peru, Argentina | Showroom Location: | Indonesia, Bangladesh |
| Marketing Type: | Hot Product 2019 |
| Brand: KELIER | Model: FC20/30/50G | Origin: Mainland China |
| Provinces: Sichuan | City: Chengdu | Power: 20W/30W/50W |
| DCarving speed:0-9000mm/s | Voltage: 110V-240V | Weight: packing weigth:120kg |
| Name:co2 laser printer automatic date code printing machine 30 20 watt fiber laser marking machine | ||
| -Description:CO2 lasers offer consistent, high-quality marking on many types of materials on the production line, including plastics, ceramics, rubber, paper and fiber products. KELIER CO2 laser marking systems are designed for easy integration into production lines and automation cells with their sturdy cabinets, rotating marking heads, and internet-ready controls. | ||
Features of CO2 laser marking machine:
1. The laser marking machine takes CO2 glass laser tube as the light source. By 2D fast-speed scanning lens swinging as the scheduled angles under the controlling of the computer, the laser focus on the surface of the work piece by F-θ lens to form images and realize marking and graph processing.
2. The CO2 laser marking machine has the longest application time and the most extensive usage areas and is the most mature technology at present.
3. By using fast-speed scan lens, it can scan the graph in shortest time finish fine marking process.
4. It can configure auto clamp and baiting production line as user’ s requirements.
5. It can mark data, series number bar code automatically.
6. It is available for data communications, networking.
CO2 Cabinet Optical Fiber Laser Marking Machine characteristics
1. The CO2 laser marking machine uses the original American RF metal laser tube as the laser source, and its lifetime can reach 30,000-40,000 hours without maintenance.
2. The beam quality of CO2 laser marker is excellent, stable and the marking is more fine and smooth.
3. CO2 laser marking machine can complete image scanning and fine marking in a very short time by using high-speed scanning lenses.
4. Automatic fixture and loading and unloading production line can be configured according to user's requirements. It can automatically complete the date, flow number and mark bar code.
5. CO2 laser marking machine adopts mechanical moving parts with simple structure, wear resistance and corrosion resistance, which makes the system have good stability and high motion accuracy.
6. The CO2 laser marking machine can operate at 24 hours'load to meet the requirement of mass production.
7. Environmental protection and green is the environmental protection marking solution;
8. KELIER laser operation software, friendly and simple interface, workers can quickly start.
| KELIER Industrial Laser Marker parameters | |
| Optional Model | FC20G/FC30G/FC50G |
| Laser power | 20W30W50W(optional) |
| Laser source | China DAVI or CRD CO2 laser-Support customization |
| Laser wavelength | 1064 nm |
| Beam quality | M2 < 1.4 |
| Modulation frequency | 20kHz~100kHz |
| Marking range | 30mm x 30mm - 300mm x 300mm can be optional |
| Carving speed | ≤7000 mm/s(Adjustable) |
| Carving depth | 0.01~0.4mm(10W) ; ≤1.0mm(50W) according to material |
| Focusing mode | Support for automation or manual |
| Marking speed | 1500-2000characters/Min |
| Minimum line width | 0.001 mm |
| Minimum characters | 0.15 mm |
| Repeatability accuracy | ±0.002 mm |
| Cooling method | Air Cooling |
| Use environment | IP4 Clean, dustless or less dusty |
| Laser type | Pulse or continuous |
| control software | NOAH marking control software |
| Graphic format supported | bmp, jpg, gif, tga, png,tif,ai,dxf,dst,plt,etc. |
| Laser indicator | Double Red dot pointer |
| Operating system | Win98/Win2000/WinXP/win7 (64,32bit)win8/win10 |
| working temperature | 0-35 ℃,90% or humidity |
| Power consumption | ≤ 550 W |
| Electricity demand | AC110V-240V±10%,50 HZ/60HZ |
| This product contains computers. The following is the configuration list of the dedicated computers. | |
| Computer configuration parameters | |
| CPU | Intel G630X2/I3 540 |
| Memory | ADATA 4G/8G DDR3L 1600 |
| BIOS | AMI EFI BIOS |
| Super I/O | Winbond W83627DHG-P / HG41/HG55 |
| Ethernet | 1x LAN Intel I211(IO) |
| GPU | Intel HD Graphics |
| Display interface | 1x HDMI:1920×1200@60Hz |
| Hard disk | 60G/120G/500G |
| USB interface | 4xUSB |
| serial port | 1x RS232,COM1,RS422,RS485 |
| operating system | Windows 7 32bit;Can support/Windows 8/Windows 10/Linux |
| working temperature | 0℃~ 60℃ |
| Storage temperature | -40℃~ 85℃ |
| humidity | 5% ~ 95% Relative humidity, no condensation |
KELIER laser made high-speed CO2 laser marking machine, with its excellent quality, exquisite marking effect and intimate pre-sale and after-sales service, won the attention and trust of the majority of users. KELIER laser products cover all over the world and serve many companies around the world. This series of models have passed the international CE certification.
KELIER laser produced high-speed CO2 laser marking machine is suitable for marking non-metallic materials and some metal materials, such as paper packaging, plastic products, label paper, leather cloth, glass and ceramics, resin and plastic, bamboo and wood products, PCB board, etc.
Application industry:
CO2 laser marking machine is widely used in the marking and cutting of graphics and words in garments, leather, food and beverage packaging, electronic components, crafts, glass and stone processing and other fields. CO2 laser marking machine is suitable for marking most non-metallic materials, such as paper packaging, plastic products, label paper, leather fabric, glass and ceramics, resin and plastic, bamboo and wood products, PCB board, etc.
| Packing list | ||
|
It is composed of fiber laser, high-speed scanning mirror, control software, computer, switching power supply control chip set and precision Z-axis elevator.
Inside: Shockproof multilayer foam packaging high-end, safe, easy to carry and store; support customized packing.
|
||
| Packaging size/weight(mm):900(L)*800(W)*1060(D) / 120KG | ||
| Part name | Brand origin | Quantity |
| Fiber laser | China DAVI or CRD | 1 sets |
| High speed scanning galvanometer | Beijing SINO GALVO | 1 sets |
| Focusing lens | Singapore wavelength | 1 sets |
| Marking software | EZCAD/NOAH | 1 sets |
| Indicator locator | Xi'an sapling | 1 sets |
| Power switch | Taiwan Meanwell | 1 sets |
| Laser frame | Self-control | 1 sets |
| Print foot | Customized | 1 sets |
| Equipment switch | Shanghai Jia Jia | 1 sets |
| Control computer(Include) | desktop computer | 1 sets |
| Rotary Printing Table (Order) | Dongsheng Precise | 1 sets |
| Instructions |
Video, text and pictures |
1 sets |
| Shipping Method |
|
1. By Express: DHL, UPS, Fedex, a fast and safe way for shipping, normally 3-5 working days for delivery; |
|
2. By Air: In some areas, the shipping cost by air is more favorable than by Express; 5-7 working days for delivery; |
|
3. By Sea: the most economical shipping method, but it will take longer shipping time;suitable for large-quantity, heavy and non-urgent goods. |
|
4. Your shipping agent or forwarder. |
| Information you need to know before buying |
|
1.after the order confirmed. 24-hour full after sales service: our skilled engineer will help customer to solve the problem by Whatsapp,wechat,SKYPE,QQ etc in time when problems happen, if necessary, overseas service is available. |
|
2. Quality Control Skilled and strict Quality Inspection Team is available during the material purchasing and production procedure. All finished machine we delivered are 100% strictly tested by our QC department and engineering department. |
|
3. OEM Service Customized and OEM orders are welcome due to our aboundant experiences. All the OEM services are free, customer only need to provide us with your logo drawing, function requirements, colors etc. No MOQ required. |
|
4. Privacy None of your personally identifiable information ( such as your name , address , email address ,bank info ,etc ) will be disclosed or shared with any third parties. Contact: All of your inquiries or questions or helps will be answered within 24 hours, even in holiday. Also, please feel free to call us if you have any emergency questions. |
Q1:How to distinguish laser tubes with different powers and applications?
A:Laser tube length (relatively speaking, the longer, the bigger)
B:Laser tube diameter (relatively speaking, the thicker, the bigger)
C:The bigger a laser tube power is, the deeper the machine can cut, but its light spot is bigger.
So, it is better to use a machine with a low-power laser tube to engrave, such as 20w 30w .
Q2:Please let us know following information:
A. What materials you want to mark ?
B. How many products you want to mark per day?
C. What is the MAX working area ?
Q3: What’s the package?
A: We have 3 layers package. For the outside, we adopt wood craft case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by thickening plastic bag for waterproof.
Q4: Will the package damaged during transportation?
A: Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 180 countries worldwide. So please don’t worry, you will receive the parcel in good condition.
Q5: How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user’s manual along with the machine. 95% customers can
learn by themselves.
Q6: How can I do if the machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Q7: Is it easy to operate the laser marking machine for the new user ?
A:It is very easy,we offer you manual book and operatevideo,also our technician can help you via MSN,Skype teamviewer etc.
Q8.What i need to do when the laser marking machine suffer trouble ?
A:Make sure all the wires be connection well ,and keep your lens and mirrors be clean ,then check your laser tube and talk details to us.
Q9.How to maintain the laser marking machine?
A:After 8 hours working,it’s better close 10 minutes.
B:Keep lens and mirrors clean.
